How big does the studio floor need to be?
This is the question that opens most first conversations, and the honest answer starts with the programme rather than the room. A two-person interview set and a three-camera panel show can share a footprint, but a show with a standing presenter, a demonstration area and a guest sofa cannot. We ask what the busiest shot looks like, how many people are in it, and how far the cameras must sit from the action to hold the framing the producer wants.
Lenses matter here. A camera that needs a wide shot of the whole set has to back away from it, and that distance has to exist on the floor. We usually sketch the set in plan first, draw the camera positions around it, and only then measure the room. Many teams discover that the set is the smaller part of the space and that the circulation around it is what decides whether the room feels workable.
- Count the people in the widest shot
- Allow camera travel on at least two sides
- Leave a clear walkway behind the set
Where should the cables actually run?
Cable routing is rarely the first thing a client raises, yet it causes more day-to-day irritation than almost any other part of a studio. Our advice is to decide the routes on the floor plan before a single box is bought. Camera, audio and lighting cables each want their own path, and keeping them apart reduces both interference and the temptation to step over a bundle in the middle of a take.
In practice that means floor boxes near the set, trunking along the walls to the control room, and a clear separation between mains power and signal where the two must cross. Cross them at right angles and keep the crossings few. We also leave spare capacity in every route, because a studio that is full on the day it opens will not stay that way for long. It is far cheaper to pull an extra cable through a spare duct than to open a wall.
- Separate mains from signal runs
- Cross unavoidable routes at right angles
- Fit spare ducts at the start
Should the control room sit next to the studio?
Producers often ask whether the gallery must be beside the floor. It helps, because the director can walk through to talk to talent and a short run keeps cable lengths sensible. But adjacency is not essential. What matters is that the control room has a clear view of the set, either through a window or through a good monitor wall, and that sound from the floor does not leak into the people making critical decisions.
We have planned rooms where the gallery sits above the floor, behind glass, and others where it is a separate room with only monitors. Both worked because the sightlines and the talkback were considered early. If you are converting an existing building, look first at which rooms already share a wall with a quiet corridor. That is often a better starting point than the largest room, which tends to be chosen for the studio and leaves the gallery with whatever is left.
How does lighting shape the layout?
As the company's lighting lead, I am asked this more than people expect, because lighting is usually treated as something added after the room is chosen. It should be considered during the plan. The ceiling height decides how far lamps can sit from the talent, and a low ceiling forces compromises on angle and heat that no amount of equipment will fix.
I look at the ceiling first: its height, its structure and whether a grid or hanging bars can be fixed to it. Then I check where the set will sit and whether daylight reaches it through windows, which usually need blackout. A lighting grid should cover the whole floor rather than only the first set, so that the room can change shape later. Power for lamps also needs its own circuits, planned with the electrician rather than discovered on the first day of rehearsal.
- Measure usable ceiling height first
- Plan blackout for any windows
- Give lamps their own power circuits
What about sound and room acoustics?
A studio that looks right can still sound poor, and clients are often surprised by how much of the work is acoustic. Hard parallel walls, glass and bare floors all produce reflections that the microphones pick up. Treating the room does not mean covering every surface in foam; it means placing absorption where it removes the worst reflections near the set and leaving the rest of the room alone.
Noise from outside is the other half. Air handling, traffic and neighbouring rooms all find their way into a quiet interview. We ask early where the ventilation sits and how loud it is, because a unit that is acceptable in an office can ruin a take. Fixing it after the build is expensive, while moving a duct on paper costs nothing. For that reason the audio engineer's view belongs in the floor plan stage, not at the end.
What should be settled before ordering equipment?
The most useful step a client can take is to hold off buying until the plan is agreed. Equipment chosen first tends to dictate a layout that does not suit the room, and returns are rarely simple. We recommend a short written brief covering the programmes, the number of cameras, the crew size and the delivery format, because each of these changes what the room must hold.
From that brief we produce a floor plan, a cable route drawing and an equipment list that matches both. Teams can then compare quotations on the same basis and see where money is being spent. If the budget is tight, the plan also shows which parts can be added later without disturbing the rest, which is usually a more comfortable position than having bought everything at once and fitted it badly.
- Write down programmes, cameras and crew
- Agree the plan before the equipment list
- Mark what can be added later
Most of the questions about studio design come down to the same habit: decide on paper what the room must do, then buy and build to that. Floor space, cable routes, the gallery, lighting height and acoustics all connect, and each is cheaper to settle in the plan than on site. If you are weighing a studio project this autumn, bring us the programme and the room, and we will start from there.
